Here is a comprehensive guide with tips and technical knowledge for Vibrating Level Switches (also known as vibrating forks), essential for point-level detection in various industries
Here is a comprehensive guide with tips and technical knowledge for Vibrating Level Switches (also known as vibrating forks), essential for point-level detection in various industries.
How It Works: The Principle
A vibrating level switch uses a piezoelectric crystal to electronically oscillate a tuning fork at its mechanical resonant frequency (typically around 100-400 Hz).
- Free in Air (No Material): The fork vibrates freely at a specific frequency and amplitude.
- Immersed in Material: The surrounding material (liquid or solid) dampens the vibration. An internal electronic circuit detects this change in amplitude and/or frequency and triggers a solid-state or relay output.
Key Advantage: Simple, reliable, no calibration needed, and largely unaffected by material properties like dielectric constant, density, or conductivity.
1. Key Selection Criteria
Parameter | Consideration | Recommendation |
Material of Construction | Process Compatibility | SS316L: Standard for most applications. Hastelloy C-276: For highly corrosive chemicals. PTFE/ PFA Coating: For sticky materials (e.g., glue, syrup). |
Process Connection | Tank Thread/Flange | 1" NPT: Very common. Tri-Clamp: Sanitary applications (food, pharma). Flanged (DN50, etc.): High pressure or larger connections. |
Output Type | Control System Interface | SPDT Relay (DPDT also common): Easy wiring, for PLC discrete inputs. NPN/PNP Transistor: High-speed switching, solid-state. |
Power Supply | 120~230VAC or 24VDC. | Check nameplate. |
Temperature Range | Standard: -40°C to 80°C High-Temp: Up to ~150°C with special seals. | Operating temperature range. |
2. Application-Specific Selection: Liquids vs. Solids
Feature | Liquid Level Switch | Solid Level Switch |
Fork Design | Short, stubby tines | Longer, reinforced tines. |
Sensitivity | High sensitivity detects low-density liquids. | Lower sensitivity requires more force to dampen. |
Typical Use | High/low level alarm, pump control. | Bin, hopper, silo high/low level detection. |
Mounting | Top-mounted (vertical or horizontal). | Side-mounted (for high level) or top-mounted (for low level). |
Crucial Tip: Do not use solids switch for liquids or vice versa. A solids switch is not sensitive enough for most liquids, and a liquids switch can be damaged by the constant abrasion and higher force from solids.
3. Installation Tips (Where 90% of Problems Occur)
For Liquids:
- Avoid mounting directly in the material inlet stream, which can cause false switching or physical damage.
- For agitators, install the fork where flow is minimal or use a still-well (bypass chamber).
- Ensure the fork is long enough to clear the tank wall or any welds.
For Solids (Silos/Hoppers):
- Side-Mounting (High Level): Install on the side wall, angled downward 15-30 degrees to prevent material pile-up on the fork and allow self-cleaning during discharge.
- Top-Mounting (Low Level): Install so the fork is clear of the outlet but where it will reliably detect the empty condition.
- Keep clear of filling streams and impact points.
General:
- Grounding: Properly ground the device to protect electronics from surges.
- Wiring: Use conduit glands to ensure a dust-tight and water-tight seal (IP66/IP67 rating is common).
4. Configuration and Commissioning
1. No Calibration Needed: These are typically "plug-and-play." The operating point is factory setting.
2. Test Function: Most have a test button to manually force the output and verify wiring to the control room.
3. Output State: Configure the relay as Normally Open (NO) or Normally Closed (NC) based on your safety philosophy (e.g., Fail-Safe).
- Example: For a high-level alarm to stop a pump, you might want the switch to be NC. If the cable is cut or power is lost, the alarm will trigger, failing to a safe state.
5. Maintenance & Troubleshooting
Problem | Likely Cause | Solution |
False "High Level" Alarm (Fork clean) | Material buildup on fork or housing. | Clean fork. For sticky materials, select a model with a PTFE coating |
No Switching | Fork damaged (bent or broken). | Replace the sensor. Check if a solids model was used in a liquid application. |
Electronics dead | Wiring error, power surge, or moisture ingress. | Check power, fuses, and conduit seals. |
Erratic Operation | Heavy vibrations from nearby machinery. | Install vibration isolators or relocate the switch. |
By following these guidelines, you can ensure reliable and accurate level measurement with vibrating level measurement technology.
